3-Roll Hydraulic Plate Bending Machine

The 3-roll hydraulic plate bending machines produced by ACCURL are able to bend easily the metals sheets with thickness of 2 mm to 200 mm and width of 1000 mm to 12000 mm in high quality.

3-Roll Hydraulic Plate Bending Machine

AHK machines have extremely strong bodies in view of the welded St-52 steel structure. The bending moment is produced by NC or CNC panel control system.

Three rolls are driven by three separate hydraulic motors and / or reducers (rolls of ø 230 mm, machine and its top). All the rolls of our bending machines produced by ACCURL are embedded with self-aligning roller bearing. In this way, the friction force is reduced, and the machine is strengthened.

It is offered various options to facilitate the process of bending.

Options
1. Stepless regulation of rotation speed
2. Side and central supporters for metal sheets of big diameters
3. Extended spindles
4. Profile of rolls
5. Material feeding table
6. Oil cooling system

Standard Equipment
1. Cone bending device
2. Induction hardened rolls
3. Digital display for both side rollers
4. Machine body is steel (St-52) construction
5. Separate control panel
6. All rollers mounted in bearing
7. Drop end controlled by control panel in order to release easily bent metal sheet and lifted upper rolls.
8. Movement and parallelism adjustment of the rollers controlled from panel.
9. All rolls are driven by hydraulic motor and planetary gear box.
10. CE, ISO 9001-2008, TSEK and TURQUM certificates

Optional Equipment
1. Side and central supporters for metal sheets in big diameters
2. Extended rolls
3. Profile rolls
4. Material feeding table
5. Changeable top roll with smaller diameters
6. Oil cooling system
